Marine double suction mid-open horizontal centrifugal pump

marine double suction mid-open horizontal centrifugal pump
Precio:USD$3,500.00

Descripción

  marine double suction mid-open horizontal centrifugal pump
China Deyuan Marine Fitting Co.,ltd are leading supplier of marine pumps,such as marine diesel emergency fire pump,vortex marine water pump,marine centrifugal water pump etc.Pls contact us for more details.
The CWS type pump is a single-stage double suction mid-open horizontal centrifugal pump.It is used to deliver the fresh water and the liquids physically and chemically similar to water.If the overflow component is made of stainless steel or coated with SEBF high-performance epoxy powder coating,it can also be used to deliver the corrosive liquids.The maximum temperature of the delivered liquids shall not exceed 80℃. It is suitable for water supply and drainage in factory,mining ore,city and power station as well as for flood control and irrigation works of agricultural fields.It always used in the capital ship and Float Boatyard.
The pump rotates anticlockwise viewed from motor.
Type (50HZ,3phase,380v)main technical parameter Power (kw)
Capacity
(m3/h) Head
(m) Speed
(r/minZ) NPSHR
(m) Shaft power
(kw)
150CWS-8.5 125 54 2950 25.2 37
160 50 3.8 28.1
200 42 29.7
150CWS-8.5A 105 44 2950 17.5 30
140 40 3.8 20.3
170 35 21.9
150CWS-8.5B 100 39 2950 16.3 22
130 36 3.1 18.2
160 32 19.4
150CWS-6 125 84 2950 39.7 55
160 78 3.3 46.9
200 70 52.2
150CWS-6A 105 65 2950 27.3 45
140 60 3.3 31.8
170 54 35.7
200CWS-13 210 48 2950 33.9 45
280 42 6.3 39.3
335 35 40.4
200CWS-13A 200 43 2950 30.8 37
270 36 6 33.1
325 30 34.9
200CWS-9 210 68 2950 50.2 75
280 63 5.7 60.4
335 58 64.1
200CWS-9A 180 55 2950 36.4 55
245 48 5.5 41
295 40 42.8
More types can be offered,pls contact us directly for more details.

&&&&&&:
