Quick Opening And Closing Steel Watertight Door
Descripción
Quick Opening And Closing Steel Watertight Door
China Deyuan Marine Fitting Co.,ltd are leading supplier of marine outfitting equipment,such as marine steel doors,marine aluminum door,marine windows,marine hatch cover,marine pilot rope ladder,embarkation rope ladder,gangway ladder ,bulwark ladder etc.
Code of
standard Size of doorway
H*W*R Size of door
(H1*W1*R1) Hole size of casting wall
(H2*W2*R2) Thickness of
door sheet Weight
(kg)
1050 1000*500*100 1049*549*124.5 1100*600*150 6 92.3
1050*551*125.5 8 103.8
1260 1200*600*100 1249*649*124.5 1300*700*150 6 113.4
1251*651*125.5 8 129.0
1460 1400*600*100 1449*649*124.5 1500*700*150 6 128.6
1451*651*125.5 8 146.7
1475 1400*750*100 1449*799*124.5 1500*850*150 6 144.4
1451*951*125.5 8 165.9
1490 1400*900*100 1449*949*124.5 1500*1000*150 6 160.1
1451*951*125.5 8 185.2
1660 1600*600*100 1649*649*124.5 1700*700*150 6 136.9
1651*801*125.5 8 154.8
1675 1600*750*100 1649*799*124.5 1700*850*150 6 161.4
1651*951*125.5 8 185.7
1690 1600*900*100 1649*949*124.5 1700*1000*150 6 178.0
1651*951*125.5 8 206.4
&&&&&&:
